| Model | KM-15B | |
| Spindle I.D. | mm | 93 |
| Spindle rotation | rpm | 30 – 130 |
| Torque | kN-m | 3.5 – 25.0 |
| Spindle stroke | mm | 600 |
| Thrust (forward) | kN | 45 |
| Thrust (backward) | kN | 57 |
| Hoisting capacity | kN | 30 |
| Prime mover – Motor | kW-P | 11-4 |
| Prime mover – Engin | ps | 13-20 |
| Dimensions | mm | 2,230 x 1,140 x 1,550 |
| Weight (without engine) | kg | 1,400 |
*This list is the original specification just for your reference.
