RVD-50C

Home > Products > RVD-50C
RVD-50C

Primary Use :
Wate well drilling / Grout hole drilling
Key Feature : RVD-50 is as Vi-bro type of RPD-50C. So it has good manuevability because of this compact size hull and seperated engin unit.

Model RVD-50C
Drlling dia. mm Max.157
Bit rotation rpm 25(Low)/50(High)
Torque kN-m 5.6(Low)/2.8(High)
Frequency Hz 42
Vibratory force kN 53
Thrust kN 20(Push)/60(Pull)
Length stroke mm 1,700
Power unit kW/rpm 45/1,700
Dimensions(Drill unit only) mm 3,700x980x1,850
Weight(Drill unit only) kg 2,500
RVD-50C
